P/N - Description - Application

• G128x1353-4 - Manifold Section - for Single Pipe Manifolds
• G128x1404 - Clamp - for Single Pipe Manifolds
• G128x1413 - Gasket At Turbo Transition - for Dual Pipe Manifolds
• G128x1444-7-  Transition Section - for Single Pipe Manifolds
• G128x1495 - Complete Manifold - 8 Cylinder - SS Version
• G128x1496 - Manifold Section - Leg 1R & 4R - 8 Cylinder - SS Version
• G128x1497 - Manifold Section - Leg 1L & 4L - 8 Cylinder - SS Version
• G128x1498 -  Manifold Section - Leg 2R & 3R - 8 Cylinder - SS Version
• G128x1499     Manifold Section - Leg 2L & 3L -  8 Cylinder - SS Version
• G128x1629 - End Cover - for Dual Pipe Manifolds
• G128x1635 - Main "T" Section - for Dual Pipe Manifolds
• G128x1636 - Bellows Connector - for Dual Pipe Manifolds
• G128x1637 - Gasket At Sections - for Dual Pipe Manifolds
• G128x1638 - Transition Section - for Dual Pipe Manifolds
• G128x1639-1 -  V-Band Clamp - for Dual Pipe Manifolds
• G128x1640-2 - Complete Manifold - 16 Cylinder Dual Pipe
• G128x1642-2 - Complete Manifold -12 Cylinder Dual Pipe
• G128x1648-1 - Transition Section - for Dual Pipe Manifolds
• G128x1657 - Manifold Section - Leg 1R & 4R - 8 Cylinder - SS Version
• G128x1658 - Complete Manifold - 8 Cylinder - SS Version
• G128x1659 - Manifold Section - Leg 1L & 4L - 8 Cylinder - SS Version
• G128x1660 - Manifold Section - Leg 2R & 3R - 8 Cylinder - SS Version
• G128x1661 - Manifold Section - Leg 2L & 3L - 8 Cylinder - SS Version
• G128x1670 - Complete Manifold - 12 Cylinder Dual Pipe

567 Chambers - 645 Chambers - 710 Chambers

• E9316231 - Chamber Assembly 12-645 - Exhaust - Front
• E9516746 - Chamber Assembly 12-645 - Exhaust - Rear
• E9316231 - Chamber Assembly 16-645 - Exhaust - Front
• E9316232 - Chamber Assembly 16-645 - Exhaust - Intermediate Front
• E9316233 - Chamber Assembly 16-645 - Exhaust - Intermediate Rear
• E9316234 - Chamber Assembly 16-645 - Exhaust – Rear

THERMASEAL

Increased Thickness for INCREASED Bolt Retention

Ceramic-filled with Proprietary Material to Increase Working Temperatures of approx. 2,000° F.

• E8408987- Expansion Joint 10" -  Adaptor to Turbo
• E8408985 - Expansion Joint 14" - Exhaust Chamber
• E40026936RED - High Heat Therma Seal / Gasket  21.625 OD x 18.875 ID, 12 Bolt Holes - Exhaust Chamber
• E40026937RED - High Heat ThermaSeal Gasket 18.375 OD x 16.00 ID, 9 Bolt Holes - Expansion Joint to Chamber
• E40055466RED - High Heat ThermaSeal Gasket – All Metal 410 Stainless Non-Graphite Design - Exhaust Chamber
• E40026939RED - High Heat ThermaSeal Gasket 3.625 OD x 11.25 ID, 10 Bolt Holes - Expansion Joint to Turbo
• E8287827PRD - Bolt ½-20 x 2 Hex Head B14 - Expansion Joint Exhaust
• E9338626 - Nut ½-20 Silver Plated 316 Stainless Steel -Exhaust Manifold / Expansion Joint
• E9557143 -Turbo Screen Assembly 410 Stainless Steel Screen Starburst Design - 645

• E40155024 - Turbo Screen Assembly - 710
